Air Flow 12000m3/H 6 Ton Central Air Unit Dual Refrigeration System
Contact Person : Daisy
Phone Number : 86-13425728677
WhatsApp : +8613425728677
| Minimum Order Quantity : | 1 unit | Price : | 1000USD-5000USD/unit |
|---|---|---|---|
| Packaging Details : | standard pallet packing | Delivery Time : | 30-60days |
| Payment Terms : | L/C, T/T, Western Union | Supply Ability : | 50 Containers Per Month |
| Place of Origin: | CHINA | Brand Name: | VENTECH |
|---|---|---|---|
| Certification: | CE | Model Number: | VH Series |
|
Detail Information |
|||
| Product Name: | Fan Coil Unit | Material: | Best |
|---|---|---|---|
| Application: | Air Conditioning | Quality: | Superior |
| Standard: | International Standard | Price Term: | FOB/CIF/EXW |
| Payment Term: | TT/LC | Keyword: | Central Air Conditioner |
Product Description
VENTECH(Vcare) Package FCU--Horizontial packag
| VWG horizontal unit H series data | |||||||||||||||
| Model | Air flow (m3/h) |
Cooling(kW) | Heating(kW) | ESP (Pa) | Motor power(kW) | ||||||||||
| 4-row | 6-row | 4-row | 6-row | 4-row | 6-row | ||||||||||
| Return air | Fresh air | Return air | Fresh air | Return air | Fresh air | Return air | Fresh air | I | II | I | II | I | II | ||
| VWG050H | 5000 | 29.0 | 64.2 | 38.5 | 83.2 | 43.2 | 71.9 | 57.3 | 94.8 | 150 | 300 | 1.1 | 1.1 | 1.1 | 1.5 |
| VWG060H | 6000 | 35.5 | 70.9 | 47.0 | 96.5 | 52.9 | 79.4 | 70.0 | 110.0 | 160 | 300 | 1.5 | 1.5 | 1.5 | 2.2 |
| VWG070H | 7000 | 43.0 | 87.3 | 56.1 | 115.8 | 64.1 | 97.8 | 83.6 | 132.0 | 170 | 350 | 1.5 | 2.2 | 1.5 | 2.2 |
| VWG080H | 8000 | 50.3 | 102.2 | 65.2 | 129.8 | 74.9 | 114.5 | 97.1 | 148.0 | 180 | 350 | 1.5 | 2.2 | 1.5 | 2.2 |
| VWG090H | 9000 | 55.8 | 113.8 | 72.5 | 155.0 | 83.1 | 127.5 | 108.0 | 176.7 | 190 | 350 | 2.2 | 2.2 | 2.2 | 3.0 |
| VWG100H | 1000 | 60.0 | 130.0 | 77.5 | 169.3 | 89.4 | 145.6 | 115.5 | 193.0 | 200 | 400 | 2.2 | 3.0 | 2.2 | 3.0 |
| VWG120H | 12000 | 74.3 | 151.8 | 94.5 | 203.2 | 110.7 | 170.0 | 140.8 | 231.6 | 210 | 400 | 3.0 | 4.0 | 3.0 | 4.0 |
| VWG140H | 14000 | 86.0 | 179.5 | 110.9 | 241.2 | 128.1 | 201.0 | 165.2 | 275.0 | 220 | 400 | 3.0 | 4.0 | 3.0 | 4.0 |
| VWG160H | 16000 | 100.7 | 211.7 | 130.3 | 266.1 | 150.0 | 237.1 | 194.1 | 303.4 | 230 | 450 | 4.0 | 5.5 | 4.0 | 5.5 |
| VWG180H | 18000 | 115.8 | 240.3 | 146.6 | 302.0 | 172.5 | 269.1 | 218.4 | 344.3 | 240 | 450 | 4.0 | 5.5 | 5.5 | 7.5 |
| VWG200H | 20000 | 131.6 | 269.3 | 164.8 | 326.7 | 196.1 | 301.6 | 245.6 | 372.4 | 250 | 450 | 5.5 | 7.5 | 5.5 | 7.5 |
| VWG220H | 22000 | 136.3 | 277.0 | 177.3 | 338.6 | 203.1 | 310.2 | 264.2 | 386.0 | 260 | 500 | 5.5 | 7.5 | 7.5 | 11.0 |
| VWG2S0H | 25000 | 157.3 | 330.8 | 202.5 | 407.0 | 234.4 | 370.5 | 301.7 | 464.0 | 270 | 500 | 7.5 | 11.0 | 7.5 | 11.0 |
| VWG280H | 28000 | 176.1 | 359.1 | 226.8 | 485.2 | 262.4 | 402.2 | 337.9 | 553.1 | 280 | 500 | 7.5 | 11.0 | 7.5 | 11.0 |
| VWG300H | 30000 | 191.6 | 390.0 | 245.8 | 509.2 | 285.5 | 436.8 | 366.2 | 580.8 | 290 | 550 | 11.0 | 11.0 | 11.0 | 11.0 |
| VWG350H | 36000 | 223.6 | 438.5 | 286.7 | 596.6 | 333.2 | 491.1 | 427.2 | 680.1 | 310 | 550 | 11.0 | 15.0 | 11.0 | 15.0 |
| VWG400H | 40000 | 255.5 | 501.2 | 327.6 | 677.3 | 380.7 | 561.3 | 488.1 | 772.1 | 330 | 600 | 15.0 | 15.0 | 15.0 | 18.5 |
| VWG450H | 46000 | 276.6 | 577.0 | 374.5 | 748.5 | 412.1 | 646.2 | 558.0 | 853.3 | 350 | 600 | 7.5x2 | 11x2 | 7.5x2 | 11x2 |
| VWG500H | 50000 | 297.5 | 641.2 | 416.2 | 795.8 | 443.3 | 718.1 | 620.1 | 907.2 | 370 | 650 | 7.5x2 | 11x2 | 7.5x2 | 11x2 |
This is the most sophisticated form of air conditioning available for the home. The core cooling/heating unit is placed at one location. From that unit, a network of pipes and ducts originates that supply air to the rooms.
The central air conditioning system has a set of condenser units that provide the required heat exchange.
Air Handling Unit (AHU) – You may have heard this phrase before. The air handling unit is the furnace where the air is conditioned for temperature and humidity. It is then circulated through the ducts to the rooms. The central air conditioner typically provides both cooling and heating features.
Since the central AC is meant to cool the entire house, the capacity of the central AC system is based on the square feet area that needs cooling. Based on the climate, there are reference numbers for the cooling capacity (BTU per hour per square feet, tons per thousand square feet, kW per thousand square feet). It is advisable to have a system with some buffer capacity (15-20% higher than calculated) to take care of the efficiency decrease over time.
Digital or rotary thermostats are provided in each room for room-specific temperature control. This helps in the formation of temperature “zones” in the house, based on the temperature requirement of the occupants of the room.
❤ Want to learn more about Vcare Wholehouse air conditioner,please contact us by email directly.
