Fan coil unit Air conditioning unit central air conditioner brands

Minimum Order Quantity : 1 unit Price : 1000USD-5000USD/unit
Packaging Details : standard pallet packing Delivery Time : 30-60days
Payment Terms : L/C, T/T, Western Union Supply Ability : 50 Containers Per Month
Place of Origin: CHINA Brand Name: VENTECH
Certification: CE Model Number: VH Series

Detail Information
Product Name: Fan Coil Unit Size: Customized
Sample: Yes(in Charge) Quality: Superior
Standard: International Standard Price Term: FOB/CIF/EXW
Payment Term: TT/LC Keyword: Central Air Conditioner

Product Description

VENTECH(Vcare) Package FCU--Horizontial packag





VWG horizontal unit H series data

Model Air flow
(m3/h)		 Cooling(kW) Heating(kW) ESP (Pa) Motor power(kW)
4-row 6-row 4-row 6-row 4-row 6-row
Return air Fresh air Return air Fresh air Return air Fresh air Return air Fresh air I II I II I II
VWG050H 5000 29.0 64.2 38.5 83.2 43.2 71.9 57.3 94.8 150 300 1.1 1.1 1.1 1.5
VWG060H 6000 35.5 70.9 47.0 96.5 52.9 79.4 70.0 110.0 160 300 1.5 1.5 1.5 2.2
VWG070H 7000 43.0 87.3 56.1 115.8 64.1 97.8 83.6 132.0 170 350 1.5 2.2 1.5 2.2
VWG080H 8000 50.3 102.2 65.2 129.8 74.9 114.5 97.1 148.0 180 350 1.5 2.2 1.5 2.2
VWG090H 9000 55.8 113.8 72.5 155.0 83.1 127.5 108.0 176.7 190 350 2.2 2.2 2.2 3.0
VWG100H 1000 60.0 130.0 77.5 169.3 89.4 145.6 115.5 193.0 200 400 2.2 3.0 2.2 3.0
VWG120H 12000 74.3 151.8 94.5 203.2 110.7 170.0 140.8 231.6 210 400 3.0 4.0 3.0 4.0
VWG140H 14000 86.0 179.5 110.9 241.2 128.1 201.0 165.2 275.0 220 400 3.0 4.0 3.0 4.0
VWG160H 16000 100.7 211.7 130.3 266.1 150.0 237.1 194.1 303.4 230 450 4.0 5.5 4.0 5.5
VWG180H 18000 115.8 240.3 146.6 302.0 172.5 269.1 218.4 344.3 240 450 4.0 5.5 5.5 7.5
VWG200H 20000 131.6 269.3 164.8 326.7 196.1 301.6 245.6 372.4 250 450 5.5 7.5 5.5 7.5
VWG220H 22000 136.3 277.0 177.3 338.6 203.1 310.2 264.2 386.0 260 500 5.5 7.5 7.5 11.0
VWG2S0H 25000 157.3 330.8 202.5 407.0 234.4 370.5 301.7 464.0 270 500 7.5 11.0 7.5 11.0
VWG280H 28000 176.1 359.1 226.8 485.2 262.4 402.2 337.9 553.1 280 500 7.5 11.0 7.5 11.0
VWG300H 30000 191.6 390.0 245.8 509.2 285.5 436.8 366.2 580.8 290 550 11.0 11.0 11.0 11.0
VWG350H 36000 223.6 438.5 286.7 596.6 333.2 491.1 427.2 680.1 310 550 11.0 15.0 11.0 15.0
VWG400H 40000 255.5 501.2 327.6 677.3 380.7 561.3 488.1 772.1 330 600 15.0 15.0 15.0 18.5
VWG450H 46000 276.6 577.0 374.5 748.5 412.1 646.2 558.0 853.3 350 600 7.5x2 11x2 7.5x2 11x2
VWG500H 50000 297.5 641.2 416.2 795.8 443.3 718.1 620.1 907.2 370 650 7.5x2 11x2 7.5x2 11x2





Floor Standing Air Conditioner

A floor standing air conditioner is another type of split air conditioner with the difference that the indoor unit is kept on the floor. The other aspects remain the same. There is a refrigerant pipe that connects to a condenser unit outside the premises.

The floor-standing AC is typically available in higher capacities than split ductless wall mounted aircons. The standing ACs are ideal for large halls that the glass windows. The glass allows heat to be trapped inside the premises.

Since the source of heat is located at one corner of the hall, floor standing air conditioners do a better job of maintaining a uniform temperature inside. They trap the heat at the source and vent it off to the atmosphere.

Floor standing units are expensive because they typically have a capacity higher than 3 tons. Multiple fans add to the cost. However, considering the benefits of a floor standing AC, the pros outweigh the cons.
