Comfortable R410A Refrigerant Whole House Central Air Conditioner 10HP
Contact Person : Daisy
Phone Number : 86-13425728677
WhatsApp : +8613425728677
Minimum Order Quantity : | 1 unit | Price : | 1000USD-5000USD/unit |
---|---|---|---|
Packaging Details : | standard pallet packing | Delivery Time : | 30-60days |
Payment Terms : | L/C, T/T, Western Union | Supply Ability : | 50 Containers Per Month |
Place of Origin: | CHINA | Brand Name: | VENTECH |
---|---|---|---|
Certification: | CE | Model Number: | VH 051325 |
Detail Information |
|||
Application: | HVAC System | Product Name: | Central AC |
---|---|---|---|
Certificate: | CE | Business Type: | Manufacturer |
Air Volume: | 2480-4016m3/h | Heating Capacity: | Voltage |
Package: | Pallet Packing | Size: | Customized |
High Light: | Central Air Conditioner 220V,Wholehouse Central Air Conditioner 60Hz |
Product Description
VENTECH(Vcare) top 10 central a/c units healthy air conditioner for wholehouse central A/C system
Technical specification : | ||||||
Item | 12K 220V | 18K 220V | 24K 220V | |||
1 | Model name | FACTORY | Set | AS-12CR2SVE**03 | AS-18CR2SXA**02 | AS-24CR2SBB**01 |
Factory Outdoor | AS-12CR2SVE**03 | AS-18CR2SXA**02 | AS-24CR2SBB**01 | |||
Factory Indoor | AS-12CR2SVE**03 | AS-18CR2SXA**02 | AS-24CR2SBB**01 | |||
2 | mabe | Set | ||||
3 | ID | |||||
4 | OD | |||||
5 | Power supply | V/Ph/Hz | 220V~,60Hz,1P | 220V~,60Hz,1P | 220V~,60Hz,1P | |
6 | Cooling | Capacity | Btu/h | 12000 | 18000 | 24000 |
7 | Capacity | W | 3516.998827667 | 5275.498241501 | 7033.997655334 | |
8 | Input Power | W | 1134.51575086 | 1701.773626291 | 2269.031501721 | |
9 | Rated current | A | 5.3 | 7.9 | 10.280616275 | |
10 | SEER | Btu/h.W | 10.5772 | 10.5772 | 10.5772 | |
11 | EER | W/W | 3.1 | 3.1 | 3.1 | |
12 | Heating | Capacity | Btu/h | NA | NA | NA |
13 | Capacity | W | NA | NA | NA | |
14 | Input | W | NA | NA | NA | |
15 | Rated current | A | NA | NA | NA | |
16 | HSPF | Btu/h.W | NA | NA | NA | |
17 | COP | W/W | NA | NA | NA | |
18 | Moisture Removal | l/h | 1.5 | 1.8 | 2 | |
19 | Max. input consumption | W | 1500 | 2500 | 2850 | |
20 | Max. current | A | 8.1 | 14 | 16 | |
21 | Starting current | A | 28.5 | 38.5 | 61 | |
22 | Operation Control | RC | RC | RC | ||
36 | Indoor air flow (Hi/Mi/Lo) | m3/h | 580 | 950 | 1200 | |
37 | Indoor noise level (Hi/Mi/Lo) | dB(A) | 39/35 | 43/38 | 45/42 | |
67 | Outdoor noise level | dB(A) | 53 | 54 | 56 | |
68 | Outdoor dimension | Unit (WxHxD) | mm | 715x482x240 | 810x585x280 | 860x650x310 |
69 | Packing (WxHxD) | mm | 830×530×315 | 940x630x385 | 995x730x445 | |
70 | Outdoor weight | Net | kg | 25 | 38 | 39 |
71 | Gross | kg | 28.5 | 41 | 42 | |
72 | Refrigerant | Type | R410A | R410A | R410A | |
73 | Charge | g | 750 | 1000 | 1260 | |
74 | Refrigerant pipe | Liquid side | mm | 1/4 | 1/4 | 3/8 |
75 | Gas side | mm | 1/2 | 1/2 | 5/8 | |
76 | Max. refrigerant pipe length | m | 15 | 15 | 15 | |
77 | Max. difference in level | m | 5 | 5 | 5 | |
78 | Operation temperature range | ℃ | 16℃-43℃ | 16℃-43℃ | 16℃-43℃ | |
79 | Ambient temperature range | ℃ | 16℃-30℃ | 16℃-30℃ | 16℃-30℃ | |
80 | Application area | m2 | 23 | 35 | 45 | |
81 | Qty’per 20’& 40’&40HQ (with pipe) | Set | 134/280/320 | 86/180/201 | 60/128/148 |
Design a custom air conditioner like you would a bespoke suit. Pick out styles, materials and get expertly measured for the perfectly tailored end result that doesn’t exist anywhere else. Most air conditioners are purchased like pants. You find the color and style you like and hope they have your size on the shelf. There’s always the “Big-N’-Tall” for some less common uses but what if you need a different material or style or size?
Get started with the build yours button
Just like the Bespoke suites on Savile Row, building a custom air conditioner is going to be more expensive than picking something up off the shelf, but sometimes, there isn’t anything on the shelf that works for your needs…especially in an industrial setting.
We got our start modifying units for hazardous industrial and explosion-proof environments. For those not familiar with the process, to make units compliant for severe duty environments, you have to strip a unit down completely, upgrade, replace or modify every major component inside then put it all back together. It wasn’t long before customers started requesting custom air conditioners in every configuration imaginable so we broke the system down into 5 easy steps.
❤ Want to learn more about Vcare Wholehouse air conditioner,please contact us by email directly.
